Applicable |
Agriculture, Sanitation, Protection of Pests |
Tank Dimensions |
560mm x 190mm Diameter |
Tank Volumetric capacity |
15L (4 U.S Gallons) |
Tank working capacity |
12L (3 U.S Gallons) |
Steel Type |
304 No Steel, 0.55mm wall, 1.5mm Top & Bottom |
Opening Lid |
Max Size for ease filling and cleaning |
Pressure Stands |
6 to 8 Kg/Cm2 through Seal cover |
Safety |
Pressure release valve pin |
Pressure Gauge |
Steel Gauge fitted on Top |
Test Pressure |
6 to 8 Kg/Cm2. (80 Lbs. PSI) |
Working Pressure |
3 to 5 Kg/Cm2. (40-45 Lbs. PSI) |
Flow |
180-480 L/h |
Lance length |
Seamless Brass 600mm |
Housing Handle |
Brass with Shutoff valve and tubular plastic Filter |
Nozzle Tip |
Brass to produce finest spray |
Output |
1L/Min |
Lance |
600mm |
Pump Type |
Steel pump 37×450 mm |
PVC Hose |
1500mm corrosion resistant |
Shoulder Strap |
Adjustable P.V.C web (45x1000mm)with steel strap clips |
Accessories |
Washer kit, Manual |
Warrantee |
6 Months |
